Product Overview
Pressure Rating
ANSI Class 150-1500 (PN16-PN250): Class 150 (275 PSI), Class 300 (720 PSI), Class 600 (1440 PSI), Class 900 (2160 PSI), Class 1500 (3600 PSI). Excellent for throttling applications
Temperature Range
Service Temperature: -29°C to 454°C (-20°F to 850°F) for carbon steel body. High temperature service: Up to 593°C (1100°F) for alloy steel construction. Steam service: Saturated steam up to 538°C (1000°F)
Material Construction
Body: Carbon steel ASTM A216 WCB forged construction with integral seat design
Disc: 13% chrome stainless steel with hard-faced seating surface
Seat: Integral stellited renewable seat ring
Stem: 410 stainless steel with precision threads
Bonnet: Carbon steel bolted or pressure-seal design
Packing: Braided PTFE or graphite
Connection Type
Standard end connections: RF/RTJ Flanged, SW, BW, NPT Threaded per ANSI/ASME standards
Looking for more details?
View complete technical specifications in the Specifications tab, check out Features and Applications, or download product documentation from the Downloads tab.
$106.99
