Electric Actuated Ball Valve
High Performance • Durable
Electric actuated ball valves with full port design for automated isolation applications.
Technical Specifications
Key Features & Applications
An Electric Actuated Ball Valve provides automated pipeline flow control by rotating the ball 90° in response to an electrical signal. It enables remote operation and integration with plant control systems without the need for compressed air. Available in floating or trunnion-mounted designs, these valves support on/off isolation or modulating control. African Valve supplies electric-actuated ball valves for oil and gas, water treatment, power generation and industrial applications across Nigeria and other African markets.
Technical Specifications
Parameter | Specification |
Valve Type | Electric Actuated Ball Valve |
Design | Floating Ball / Trunnion Mounted |
Size Range | DN15 – DN600 |
Pressure Rating | ASME Class 150, 300, 600 |
Body Material | ASTM A216 WCB, ASTM A351 CF8 / CF8M, ASTM A352 LCB |
Ball Material | ASTM A351 CF8 / CF8M, Stainless Steel 316 |
End Connection | Flanged, Threaded, Butt Weld |
Actuator Type | Electric Quarter-Turn |
Power Supply | 24V DC, 110V AC, 230V AC, 415V AC |
Control Mode | On-Off / Modulating |
Control Signal | 4–20 mA / 0–10 V, for compatible modulating actuators |
Operation | Electric / Manual Override |
Valve Design Standards | API 608 / API 6D, ASME B16.34 |
Testing Standards | API 598 / API 6D |
Actuator Mounting | ISO 5211 |
